Available Wood Creek Granite® Cuts

Wood Creek Granite Mosaic

Mosaic

Irregularly shaped quarry material exhibiting the seam (natural) face of the stone.

Building Stone Veneer

Size:
Thickness 3″ ± to 5″ ±
Facing Area:
1/4 sq. ft. to 3 sq. ft
Coverage:
35 to 40 sq. ft. per ton
Package Weight:
3,200 to 4,300 lbs. ±

Sawn Thin Veneer

Size:
Thickness ¾” ± to 1¼” ±
Facing Area:
1/4 sq. ft. to 1¼ sq. ft.
Coverage:
150 sq. ft. dealer crate
50 sq. ft. consumer crate
Package Weight:
2,200 to 2,700 lbs. ±
1,150 to 1,400 lbs. ±

Wood Creek Granite Roughly Square / Rectangle

Roughly Squared / Rectangular

Produced on guillotines to approximate squares and rectangles and exhibiting the seam (natural) face.

Building Stone Veneer

Size:
Thickness 3″ ± to 5″ ±
Facing Area:
1/4 sq. ft. to 3 sq. ft
Coverage:
35 to 40 sq. ft. per ton
Package Weight:
3,700 to 4,400 lbs. ±

Sawn Thin Veneer

Size:
Thickness ¾” ± to 1¼” ±
Facing Area:
1/4 sq. ft. to 1¼ sq. ft.
Coverage:
150 sq. ft. dealer crate,
50 sq. ft. consumer crate
Package Weight:
2100 to 2600 lbs. ±
700 to 850 lbs. ±

Wood Creek Granite Ashlar

Ashlar

Basically rectangular in shape and exhibiting the split face of the stone revealing striations that can be quite colorful.

Building Stone Veneer

Size:
Thickness 3″ ± to 5″ ±
Height 4” ± to 12” ±
Facing Area:
1/4 sq. ft. to 2 sq. ft
Coverage:
35 to 40 sq. ft. per ton
Package Weight:
3,600 to 4,400 lbs. ±

Sawn Thin Veneer

Size:
Thickness ¾” ± to 1¼” ±
Facing Area:
Height 4” ± to 12” ±
Length 6″ ± to 20″ ±
Coverage:
150 sq. ft. dealer crate
50 sq. ft. consumer crate
Package Weight:
2100 to 2600 lbs. ±
700 to 850 lbs. ±

Wood Creek Granite Ledge

Ledge Stone

Basically rectangular and exhibiting seam and split faces of the stone, ledge stone projects a more linear appearance.

Building Stone Veneer

Size & Facing Area:
Thickness 3” ± to 5” ±
Height 3” ± to 5” ±
Length 8” ± to 12” ±
Coverage:
35 to 40 sq. ft. per ton
Package Weight:
2,800 to 4,200 lbs. ±

Sawn Thin Veneer

Size & Facing Area:
Thickness ¾” ± to 1¼” ±
Height 3” ± to 5” ±
Length 8” ± to 12” ±
Coverage:
150 sq. ft. dealer crate
50 sq. ft. consumer crate
Package Weight:
2100 to 2600 lbs. ±
700 to 850 lbs. ±

Low Pallet

Low Pallet
54” x 42” or 42” x 42”
plus headers
where applicable

Dealer Crate

Dealer Crate
42” x 42” x 30”

Consumer Crate

Consumer Crate
42” x 42” x 10”
